Broadband Military Vehicle Mount Antenna


Broadband Military Vehicle Mount Antenna

Vehicular Mount Antenna manufactured by Antenna Experts offers true omni directional radiation pattern and wide vertical / elevation beamwidth providing excellent null fill for consistent signal coverage. Many of our vehicular mount antennas are ground independent antenna which does not require any ground plane for its operation. The vehicular mount antenna features high suppression of skin current which provides the constant and superior performance over the specified frequency band.

The vehicular mount antennas manufactured by Antenna Experts for HF, VHF, UHF and Microwave bands are a crucial element of today’s demanding RF systems that are used in tactical communication, electronic countermeasure and spectrum monitoring applications. Vehicular mount antennas are ruggedized to withstand tough MIL standard of MIL-STD-810F environmental specifications making these vehicular antennas an ideal choice for installations on all kind of vehicles as well as for fixed installations like on masts, shelters or containers.

Antenna Experts provide vehicular mount antenna with high power levels from 100 – 500 W that don’t require any additional adjustments. Our highly reliable wideband antennas feature NATO 4/6 holes/ US pattern and compatible mountings fitted with stainless steel spring, making them perfect for the latest RF systems used in i.e. C3I, EW, EOD, VIP and convoy protection applications.

vehicular mount antennas are highly suitable for Electronic Counter Measure (ECM) against Radio Controlled Improvised Explosive Device (RCIED), Convoy Protection, Prisons Jamming, Large Campuses Jamming, Conference Room Jamming , VIP Protection, Cellular Jamming and Digital Bomb Jamming applications. Antenna Experts manufactures wide range of vehicular mount antennas for Radio-Controlled Improvised Explosive Device application covering the HF VHF and UHF frequency bands including GSM, EGSM, CDMA, WCDMA, AMPS, TDMA, UMTS, 3G, 4G, LTE, WLAN, ISM, GPS, Wi-Fi, Satellete and Bluetooth bands.

The AVM series vehicle mount antennas are all brass, narroband, light duty antennas and uses base loading technique for smooth impedance matching. Air-cored base loading coil keeps the losses to minimum. These vehicle mount antenna comes with a 3.5 Meter long RG-58 coaxial cable with fitted N-Male Connector. does not require any field tuning or adjustments.

Customized length of coaxial cable and connectors can also be supplied with the wide band vehicular mount whip mobile antennas. The vehicular mount antenna features high suppression of skin current which provides the constant and superior performance over the specified frequency band.

The BVM series vehicle mount antenna are broadband, heavy duty and are sealed in UV resistant ABS enclosure for complete weather protection. BVM series vehicle mount antenna can be supplied with standard side pole mounting arrangements, roof top hole mounting arrangements or NATO 4 hole pattern. Customized mounting arrangements can also be supplied on request.

Cylindrical enclosure is used for low wind loading and for minimal effect of ice formation on the broadband vehicular antenna operation as well as providing an aesthetically pleasing appearance. Due to sturdy design the broadband vehicular mount antennas are highly suitable for fixed station application, shipboard mounting and mobile application.

The BVM series broadband vehicular antennas are consisting of round diameter radiating elements stacked vertically and enclosed in ABS radome. The ABS enclosure has excellent transparency for RF signals and enough strength to withstand specified wind loads. The marine grade type 316 stainless steel mounting brackets are supplied with the vehicular antenna.

The BVM series broadband vehicular antennas are particular suitable for transmission, reception, monitoring, scanning and jamming applications due to its capability of receiving/transmitting the broad band width. The broadband vehicular mount antenna features high power handing capabilities, high efficiency, low VSWR and robust mechanical design to accommodate the most extreme environments condition.

Antenna experts provide broadband vehicular antennas for power levels from 20 - 500 W that don't require any additional tuning. Our highly reliable broadband and narrowband antennas feature NATO / US pattern compatible mountings making them perfect for the latest RF systems used in C3I, EW, EOD, VIP and convoy protection applications.

Please visit our "Vehicle Mount Antenna" section and "RCIED Jammer Antenna" section of our website for more details on vehicle mount antennas products datasheets and installation manual in pdf format. You can also request more information about NATO vehicle mount antenna like VSWR curve and radition patterns.
