Antenna Experts manufacture high gain high quality fiberglass collinear antennas for VHF 30-512MHz, 66-88MHz (75MHz band), 134-174MHz (150MHz band), UHF 300-400MHz (350MHz band), 406-512MHz (450MHz band), 700-1000MHz. (800/900MHz band) 806-870MHz High Gain TETRA Omni Directional Fiber Glass Antenna, 1350-1650MHz. (1450MHz band), 1710-1990MHz (1800/1900MHz band), 2300-2500 MHz (2400MHz band), 3000-4000MHz, 3500MHz and 5100-5800MHz frequency bands with 3dBi, 3dBd, 6dBi, 6dBd, 9dBi, 9dBd, 12dBi and 10dBd omni directional gain.
The AC series Omni directional fibreglass collinear antennas are rugged all weather models, sealed in a fiberglass tube, having excellent transparency for RF signals and enough strength to withstand specified wind loads. These glass fibre collinear antenna has been specifically designed to maintain stable vertical radiation pattern characteristics at the extremities of the tuned bandwidth. This ensures reciprocity of transmit and receive signal characteristics of our fiber glass collinear antennas.
The AC12 series fiber glass collinear antennas having a gain of 10dBd or 12dBi are two piece antenna designed for applications where the overall length of fiberglass collinear antennas for this series create transportation/logistic issues. The antenna employs a machined brass coupling to ensure long-term integrity over the entire service life of the antenna. All of our AC12 series high gain collinear antenna are supplied with stainless steel side mounting hardware consisting of 2 sets of 4.5 feet long lower support arms, upper support arm and 9 sets of cross-over mounting brackets.
In put termination of fiber glass collinear antennas is located inside the base of aluminum mounting section for complete weather protection. These Fiberglass Omni directional Collinear Antennas have excellent horizontal omni directional radiation pattern with constant gain over 360 degrees over complete horizontal plane. Antenna Experts offer a wide range of high gain fiberglass collinear antennas covering the VHF, UHF & Microwave frequency bands including TETRA, SCADA, GSM, EGSM, CDMA, WCDMA, AMPS, TDMA, UMTS, 3G and ISM application.
Antenna Experts specialized in designing and manufacturing of vertical polarized fiber glass collinear antenna with variety of omni-directional gain which start from unity to 12dBi omni gain with frequency range start from 30MHz to 6000MHz. Our AC12 series fiberglass collinear antennas are super high gain omni antenna with 10dBd. gain (12dBi) and are highly suitable for base station antenna and repeater station antenna where large bandwidth is required without having the requirement of multiple antennas.
The AC series omnidirectional fibreglass collinear antennas are rugged all weather models, sealed in a fiberglass tube, having excellent transparency for RF signals and enough strength to withstand specified wind loads. In put termination of Fiberglass Collinear Antennas is located inside the base of aluminum mounting section for weather protection. AC series fiber glass omnidirectional collinear antennas have excellent horizontal omnidirectional radiation pattern with constant gain over 360 degrees over complete horizontal plane.
A rugged and durable fireglass collinear antenna housed inside a high-strength, glass fiber enclosure and includes an stainless steel mounting clamp allowing easy installation on poles or horizontal rails. Produced to the highest quality standards, these robust high gain collinear antenna designs will ensure reliable operation in harsh environmental conditions. Omni-directional collinear antennas are available with options include 7/16 DIN-Female connectors for high power handling together with TEFLON dielectric coaxial cable which provide an IMP-rated product
A range of heavy-duty fiber glass collinear antenna with high gain to super high gain omni antenna are designed for use in communication networks. High gain fiber glass collinear antennas in this range are carefully designed to minimize low passive inter-modulation products to help reduce network interference. These omni-directional high gain collinear antennas are housed inside a high-strength fiberglass enclosure and manufactured to the highest quality standard ensuring long term reliable operation.
All of our fiber glass collinear antennas are marine variant. These collinear antennas are housed either in fiber glass radome or in ABS radome. Both are extremely rigid and highly transparent to the RF signals. The radiating elements of marine collinear antennas are made of high quality brass. Support pipe is made of 6063T6 ultra corrosion resistant architectural anodized aluminum alloy. Mounting hardware is made of type 316 marine grade stainless steel. All these features make these antennas highly suitable for marine environment.
Antenna Experts manufacture fiberglass collinear antennas for 66-88 MHz, 134-174MHz, 300-400MHz, 406-512MHz, 600-700MHz, 800/900 MHz, 1427-1535MHz, 1800/1900MHz, 2400MHz, 3500MHz and 5100-5800MHz frequency bands with 3dBi, 6dBi, 9dBi and 12dBi (10dBd. Gain) omni directional gain. The fiberglass collinear antenna consist of large diameter brass radiating elements stacked vertically, fed in phase and enclosed in fiber glass tube. The antenna termination is enclosed at bottom of the antenna for complete weather protection. The stainless steel mounting hardware is supplied with the antenna.
All our AC series omni antennas are marine variant. These antennas are housed either in fiber glass radome or in ABS radome. Both are extremely rigid and highly transparent to the RF signals. The radiating elements of fiberglass marine band collinear antennas are made of Brass and phasing systems are of Copper. Support pipe of fiberglass collinear antennas is made of 6063T6 ultra corrosion resistant architectural anodized aluminum alloy. Mounting hardware fiberglass collinear antenna is made of type 316 marine grade stainless steel. All these features make our fiber glass collinear antennas highly suitable for marine environment.
Fibreglass collinear antenna radome of 45 mm are made of an exceptionally stiff fiberglass tube, which results in a maximum tip deflection of 3° with a 3 m long tube at wind velocities up to 180 km/h. Our fiber glass collinear antennas uses multiple vertical radiating elements, stacked vertically, fed in-phase to increase the gain of omni antennas.
Please refer to our "Fiberglass Collinear Antenna & TETRA Band Antenna" section for more details on omnidirectional fiber glass collinear antenna products datasheets and installation manual. Also you can ask us for detailed datasheets of these fiberglass collinear antennas in pdf format including pictures, VSWR curves and radiation patterns.
