Antenna Experts manufactures military grade grid parabolic antennas for terrestrial point-to-point fixed station, tactical, vehicular and military radio relay applications. These state-of-the-art antennas enable increased communication range and consistent radio frequency link performance over traditional other antennas.
Antenna Experts manufacture FCC compliance grid parabolic antennas for 350MHz 330-400MHz), 450MHz (406-512MHz), 800MHz, 900MHz, 1450MHz (1427-1535MHz), 1850MHz, 2450MHz, 3500MHz (3300-3800MHz)and 4500MHz (4400-5000MHz), 5100-5900MHz grid parabolic antenna, 7700-8200MHz grid parabolic antenna frequency bands.
Various size of grid parabolic antennas manufactured by us such as 0.6Meter (60 Cms), 0.9M (90 Cms), 1.2Meters, 1.8Meters, 2.4Meters, 3Meters and 4Meters size with various gain starting from 15 dBi to 44 dBi depending on size and frequency range. Grid parabolic antennas greater than 2.4 Meters supplied with 2 side struts for highest wind load / pressure and in two segments for easy of shipping and handling.
Antenna Experts AP series grid parabolic antenna are professionally made, economically priced antennas. The grid parabolic antenna design has the highest strength/weight ratio. These grid parabolic antenna are high efficiency antennas whose gain figures approach the theoretical maximum for the individual curved surface area.
The AP series grid parabolic antenna manufactured by Antenna Experts consists of full Parabolic reflector for use in point-to-point analogue and digital communication systems. The mounting arrangement of grid parabolic Antenna permits to change the polarization from horizontal to vertical and vice-versa. Antenna Experts grid parabolic antenna consists of full Parabolic reflector for use in all tactical and fixed station applications for terrestrial radio link.
The grid parabolic antenna operates at D.C. ground with low resistance discharge path for protection against lightning and immunity to noise. All the screws, nuts and bolts of grid parabolic antenna are of type 316 marine grade stainless steel. Antenna Experts grid parabolic antenna covers wide bandwidth, operates in linear polarization and requires only one operator for small antennas and two operator for nid size grid parabolic antenna installation.
Antenna Experts grid parabolic antenna supplied with army green color. The complete grid parabolic antenna is supplied with anti-corrosive powder coating finish and the dipole feed is completely sealed inside ABS housing/radome to make the antenna 100% weather proof. The mounting arrangement of Antenna Experts grid parabolic antenna permits to change the polarization from horizontal to vertical and vice-versa by mounting hardware fitted at rear end of the antenna
The AP series grid parabolic antennas are supplied with Azimuth and Elevation tracking mechanism where the fine adjustments is necessary to optimized the signal strength of a radio link along with Two side struts to provide extra supports to the antenna. ANtenna experts grid parabolic antenna are supplied with +/-10 degrees elevation tracking mechanism.
<
Antenna Experts 2300 MHz grid parabolic antenna AP-2330-26, AP-2330-29 & AP-2330-32 are 100% in compliance with FCC part 101.115 covering directional antenna especially the front to back ratio, beam-width and cross polarization discrimination for WCS and BRS/EBS band. Grid parabolic antennas manufactured by ANtenna Experts greater than 2.4 Meters supplied with 2 side struts for highest wind load / pressure and in two segments for easy of shipping and handling.
Antenna Experts grid parabolic antenna AP-180024, AP-180027, AP-180030, AP-180032 are highly suitable for Studio-To-Transmitter STL link for broadcast application. The VSWR of these STL link grid parabolic antenna is very low i.e. better than 1.15:1. Antenna Experts grid parabolic reflector is illuminated by a primary feed which is fitted to the center of assembly with quick fastener system.
Antenna Experts offer following types of grid parabolic antenna (single polarized and dual polarized parabolic antennas for point to point terretrial microwave voice and data communication link and mailitary tactical radio relay application:
For Standard Terrestrial Point To Point Microwave Link: Please visit our “Grid Parabolic Antenna” section of our website for standard terrestrial point to point microwave voice and data communication link.
For Military Tactical Relay Relay Application: Please visit our “Tactical Radio Relay Antenna” section of our website for military tactical relay point to point microwave voice and data communication link.
