Heavy Duty VHF UHF Naval Shipboard Antenna


Heavy Duty VHF UHF Naval Shipboard Antenna

Antenna Experts manufactured MIL-STD broad band heavy duty rigid shipboard antennas. Antenna Experts marine varient shipboard antennas are used on naval ships, merchant ships and icebreaker ships. Shipboard mount discone antennas are fully welded and supplied in fully assembled condition. The fully welded wide band shipboard discone antenna uses 6063T6 Mil grade ultra corrosion resistant architectural anodized aluminum alloy with powder coating finish to protect the antenna further from severe environmental condition

Our WD series fully welded broadband shipboard discone antenna are installed on icebreaker ships in antarctica region. Antenna Experts WD series wide band shipboard discone antennas are heavy duty fully welded discone antenna which are are specially designed to survive the most extreme conditions, where conventional antennas often fail. All the screws, nuts and bolts of heavy duty wide band shipboard discone antenna are made of type 316 marine grade stainless steel.

The wide vertical beam-width of shipboard discone antennas allows clear communication for ground, sea, and ground-to-air applications. Antenna Experts fully welded shipboard discone antenna is highly suitable for Oceanic application especially in arctic region where vibration and ice loading are main concern. The powder coating on all metal surfaces of heavy duty shipboard antenna ensures complete protection from corrosive gases, ultraviolet radiation, salt spray, acid rain and sand storms in desert environments Antenna Experts extensive range of heavy duty shipboard antennas covering HF, VHF, UHF and L-Band frequency. Antenna Experts WD-75-3000 fully welded shipboard antenna cover the entire 75-3000MHz. Antenna Experts WD-100-500 heavy duty fully welded shipboard antenna cover the entire 100-500MHz band covering VHF UHF air band with single antenna.

Antenna Experts WD-500-3000 heavy duty fully welded shipboard antenna cover the entire 500-3000MHz which is supplied with radome. Antenna Expertsalso manufactured heavy duty shipboard antenna with NATO flange. Antenna Experts extended range ATC air band array system to control the vertical and horizontal beamwidth in desired plane as per the customer specific requirements.

WD-3000-6000 wide band heavy duty fully welded discone antenna is specially designed to survive the most extreme conditions, where conventional antennas often fail. Due to its low VSWR through entire band from 3000-6000 MHz., this discone antenna can be used as a transmitting and receiving antenna with high efficiency, to meet the broadband requirement of a base station antenna such as spectrum monitoring or jamming application without need of multiple antennas.

Heavy Duty Shipboard Antenna portfolio of Antenna Experts includes 100-1300MHz shipboard antenna, 108-512MHz shipboard antenna, 118-400MHz shipboard antenna, 118-470MHz shipboard antenna, 225-400MHz shipboard antenna, 75-3000MHz shipboard antenna,470-860MHz shipboard antenna VHF shipboard antenna UHF shipboard antenna MilAir shipboard Antenna.

The AWD series shipboard discone antennas are designed for broad-band omni-directional ground-based communications with aircraft. Discone Antennas are for used to communicate with VHF command radio sets in aircraft and such ground VHF stations in the terminal area. These shipboard discone antennas are designed for maximum vertical beamwidth to communicate with long range aircraft as well as nearby aircraft due to its high vertical beam-width.

The compact size of AC series omni-directional VHF/UHF aviation band shipboard antenna allows easy handling, shipping and highly suitable for shipboard application and ATC sites without having the requirement of multiple antennas. Antenna termination and feed cable lie enclosed inside the mounting pipe for complete weather protection.

Antenna Experts WD-118-400 VHF UHF aviation band heavy duty fully welded discone antenna is specially designed to survive the most extreme conditions, where conventional antennas often fail. Due to its low VSWR through entire band from 118-400 MHz., this discone antenna can be used as a transmitting and receiving antenna with high efficiency, to meet the broadband requirement of a base station antenna such as spectrum monitoring or jamming application without need of multiple antennas

Antenna Experts manufactures air traffic controller antenna for civil aviation ATC band 117.975-137 MHz and military ATC air band 225-400 MHz with various gain for directional and omni-directional properties. Antenna Experts fully welded wide band discone antenna uses 6063T6 Mil grade ultra corrosion resistant architectural anodized aluminum alloy with powder coating finish to protect the antenna further from severe environmental condition

Antenna Experts WD-75-3000 wide band heavy duty fully welded discone antenna is specially designed to survive the most extreme conditions, where conventional antennas often fail. Due to its low VSWR through entire band from 75-3000 MHz., this discone antenna can be used as a transmitting and receiving antenna with high efficiency, to meet the broadband requirement of a base station antenna such as spectrum monitoring or jamming application without need of multiple antennas

Please refer to our "Shipboard Antenna" "Coaxial Dipole Antenna" "Aviation Band Antenna" and "HF Broadband Dipole Antenna" section for more details on HF VHF UHF heavy duty shipboard antenna products datasheets and installation manual. Also you can ask us for detailed datasheets of these heavy duty shipboard antennas in pdf format. You can request more technical information of heavy duty shipboard antenna like VSWR chart and radiation patterns.
